Bringing Rehabilitation Robotics into Therapy for Stroke and Spinal Cord Injury

Our Rehabilitation Exoskeleton Platrorms

Harmony: Shoulder and Arm Exoskeleton



Harmony is an upper body exoskeleton whose development commenced in 2011 as a platform for stroke rehabilitation focussed on the shoulder. Its novel  mechanisms track the complex human shoulder joint as well as the scapular movement of the shoulder girdle. Moving coaxially with the user's skeletal structure,  Harmony maximizes the available range of motion of the human shoulder and shoulder girdle while ensuring safety with both physical and programmed interlocks. Our advanced actuator and controller technology allow Harmony to customize gravity compensation, assistance, and impedance as needed for the patient. This assist-as-needed paradigm encourages the active participation of patients. With 14 active degrees-of-freedom, Harmony powers the movement of both arms and can thus also provide bimanual therapy, which is developed based on the neurological coupling between left and right halves of the human nervous system.

BIMANUAL STRUCTURE

Harmony is the first ever rehabilitation robot capable of powering movements of both sides of the body, allowing novel therapy techniques involving both the healthy and stroke affected sides of the patient’s body.

DYNAMIC ASSISTANCE

Responding to the patient progress is a critical feature in therapy. Our advanced sensing and actuation technology provide ‘just the right amount’ of assistance to challenge users, while still enabling them to complete the exercises

ANATOMICALLY MATCHED SHOULDER DESIGN

With a 5 Degree-of-freedom shoulder joint, Harmony is the only rehabilitation robot today that can completely track the human shoulder’s anatomy, thus ensuring scapulohumeral rhythm (SHR).




Maestro: Hand Exoskeleton



Development of the Maestro hand exoskeleton began in 2012 as a single finger module for therapy focussed spinal cord injury. Maestro has since evolved into a functional hand exoskeleton that consists of a thumb, index, and middle finger modules. Mechanically and electrically robust, accurate in sensing and torque-actuation, and compatible with various rehabilitation schemes, Maestro is fabricated using SLS 3D printed technology over a lightweight aluminium core frame. Bowden cable actuation enables the exoskeleton to be extremely lightweight at just a few hundred grams.

The Maestro platform has successfully been used for a wide array of research topics including: adaptive control theories for hands movement, the study of human motor learning, novel rehabilitation frameworks,  progress of hand muscle fatigue, and EMG based intention recognition for assistance for spinal cord injury patients.

Harmonic Bionics : About us

THE FUTURE OF REHAB THERAPY

Harmonic Bionics was founded in 2016 as a spin-off of ReNeu Robotics Lab at The Univ. of Texas at Austin. We are actively developing rehabilitation robotics platforms for introduction into the clinical market, and we aim to revolutionize the fields of therapy for stroke and spinal cord injury. Our exoskeleton platforms are already being tested in pilot clinical trials and are well known in the rehabilitation robotics research community. The mission of Harmonic Bionics is to innovate the rehabilitation process with robotic technology to grant all stroke and spinal cord injury survivors an improved quality of life.

  • Utilizing the latest academic advances in robotics and controls technology

  • Supported by a strong link to academic and clinical research

  • Our robotic systems continuously gather data during therapy sessions to monitor improvement in patient outcomes

The Harmonic Bionics core team

Youngmok Yun

Chief Executive Officer/Cofounder, PhD
Youngmok is the CEO of Harmonic Bionics. He has led and participated in the development of multiple robotic and industrial automation systems over the past 12 years. A thorough technocrat at heart, he is a strong driving force behind the company’s R&D efforts.

ASHISH DESHPANDE

Chief Research Officer/Cofounder, PhD
Ashish leads and oversees all of the academic and research aspects in the development of our robots, and steers the company’s research efforts. As a professor at the University of Texas at Austin, he also directs ReNeu Robotics Lab which is our partner research group.

SUNG YUL SHIN

Head of Controls Engineering
Sung is the Lead Control Engineer of Harmonic Bionics. He has worked on various projects including development of humanoid and rehabilitation robots and motion analysis of neurologically impaired patients

ROHIT JOHN VARGHESE

Head of Product Development
Rohit John Varghese is the head of product development at Harmonic Bionics. He brings with him years of experience from the industrial automation and the automobile industries, in addition to research experience in ergonomics and physical human-robot interaction.
